Tibial Plateau Levelling Osteotomy (TPLO)
Prognosis for dogs that undergo surgical repair is good with improvement seen in 85-90% of cases. There are two bands of fibrous tissue called the cruciate ligaments in each knee joint. They connect the femur (the leg bone above the knee joint) and tibia (the leg bone below the knee joint) together. They are called cruciate ligaments because they “cross over” inside the knee joint. The cranial cruciate ligament limits the forward movement of the tibia in relation to the femur. It also limits hyperextension (over straightening) of the knee and internal rotation (turning in) of the tibia. Cruciate ligament rupture is a common knee injury of human athletes (the ACL that football players commonly injure). These “acute” or sudden ruptures can occur in dogs, but they are much less common than a process called “Cruciate Ligament Disease”. This is the name given to the complex of issues that occur in the knee as a result of cruciate injury.
-
The knee joint is a hinged joint and only moves in one plane; backwards and forwards. Cruciate ligament damage is caused by a twisting action to the knee joint. This injury usually affects the anterior or cranial (front) ligament. The knee joint then becomes unstable and causes pain, often resulting in lameness.
-
In dogs, a chronic form of cruciate damage occurs due to weakening of the ligaments as a result of disease. The reasons for this are only partially understood. The ligament may become stretched or partially torn during exercise, and lameness may only be slight and intermittent. In dogs, the top of the tibia is more slanted than in people, placing additional strain on the cruciate ligaments.
This begins a process of inflammation, or arthritis, in the joint. With continued use of the joint, the condition gradually gets worse until complete rupture of the ligament occurs in the course of normal activity. Some patients may suddenly yelp during physical activity and then become acutely lame. The activity that ruptures the ligament does not need to be violent nor excessive. 90% of cruciate ruptures in dogs occur in this way. Because this is a degenerative process, the knee joint will usually be arthritic before the cruciate disease is diagnosed. Additionally, the other knee joint usually follows suit in this progression of disease.
Clinical signs of a cruciate ligament rupture include lameness with very little weight-bearing. An injured dog usually holds the limb up or may only be intermittently lame. The treatment for this is typically surgery.
Occasionally, the cartilage within the knee joint called the meniscus can become damaged. The meniscus acts as a shock absorber between the leg bones and can cause extreme discomfort when damaged. -
A careful review of the patient's history and a complete physical examination is the first step. Many pets may "toe touch" and place only a small amount of weight on the injured leg. Your Veterinarian may perform stifle manipulations such as the "cranial drawer" or "tibial thrust" test to determine the degree of joint laxity. Other diagnostic tests such as xrays are usually necessary.
Once the cruciate ligament is ruptured, the knee joint becomes unstable, acutely inflamed and painful. This instability can result in damage of the medial meniscus (a C-shaped piece of shock-absorbing cartilage located inside the joint). This is very commonly damaged and is a source of extreme pain.
We can often feel or hear a "click" in the knee joint of dogs with meniscal damage. If left unmanaged, the knee joint becomes thickened and chronically painful. The leg muscles may waste due to disuse. -
Surgery for cruciate ligament disease aims to return patients to pain-free function and slow the progression of degenerative joint disease (arthritis). There are a number of surgical techniques used to repair the cruciate ligament and/or meniscus. Your Veterinarian will determine the appropriate surgical technique based on the size and age of the dog and the degree of damage.
-
After a careful physical examination of your dog, hip and hindlimb xrays and consideration of your home environment, your Veterinarian will advise you on the best treatment option for your dog.
-
The prognosis for dogs that undergo surgical repair is good with improvement seen in 85-90% of cases. Surgery complications are uncommon but may include meniscal injury, infection, implant failure, and soft tissue swelling.
Although surgery can slow the progression of arthritis, it is still common for dogs to develop arthritis later in life.
Studies also show that approximately 50-60% of dogs will rupture the other cruciate ligament within 2 years of each other.
Although surgery is performed to minimise all complications, they can still happen from time to time, which may require further surgical intervention:Infection rates occur in 3-5% of patients
Implant failures occur in 2% of patients
Late meniscal injury occurs in 5-15% of patients
-
At Karrinyup Small Animal Hospital, our cruciate surgery covers more than just the surgery itself; it also includes a comprehensive package of after-care, which is crucial to the success of this procedure.
This includes:Three days of post-op physical therapy (these are day stays, where your pet is dropped off to us in the morning, physical therapy is performed throughout the day and your pet is discharged in the afternoon).
Veterinary rechecks at weekly intervals for six weeks, with Pentosan Polysulphate Injections (joint support injections) given at the rechecks between weeks 3 to 6 post-op.
Post-op x-rays at 12 weeks to assess healing.
Your pet’s wellbeing is very important to us. Our Team is skilled in understanding the numerous orthopaedic conditions your pet may face.
Contact us today to discuss your pet's Cruciate Surgery plan on 9447 4644 or email vet@ksah.com.au
Common signs of a cruciate ligament rupture:Sudden, severe limping on one rear legNo or little weight bearing on the leg after an injuryMild or intermittent limping in the case of a partial tearSwelling of the knee may occurDifficulty rising or jumping
Signs
Treatment of a cruciate ligament rupture may consist of:Exercise restriction and cage rest for several weeks. This may be sufficient in small dogs and cats.Weight loss.Surgical stabilisation.Medical management of osteoarthritis.
Dogs under 10kg may improve without surgery, especially aged patients. These patients are often restricted to cage rest for four to six weeks minimum. Dogs over 10kg usually require surgery to heal.
Unfortunately, most dogs (small or large) will eventually require surgery to correct this painful problem. It is best to perform surgery early on in the disease process for the best outcome.Management
Tips to help prevent a cruciate ligament rupture:Prevent obesity as this can lead to strained jointsProvide regular exercise such as swimming to strengthen the muscles around the kneeStick to exercise that does not require a lot of twisting action or sudden stoppingAlways warm-up before strenuous exercise such as long hikes and running
Prevention
Predisposition to cruciate ligament rupture:Large and giant breeds are at a higher risk than small breedsYoung, active dogs are at higher riskOverweight dogs suffer higher levels of stress on their jointsDogs that have been hit by cars, attacked by other dogs or suffered other forms of traumaDogs that have previously injured a cruciate ligament in one knee are at an increased risk of injuring the ligament in the other knee at a later dateDogs with relatively long legs
Predispositions
These procedures aim to replace the function of the cruciate ligament and stabilise the knee joint. The extra-capsular technique involves placing a synthetic ligament on the outside of the joint capsule to "replace" the missing cruciate ligament. Some available techniques are the De Angelis and ISO toggle techniques. The disadvantage of these techniques is the break-down or failure of the synthetic ligament before the knee joint can produce enough scar tissue to stabilise.The intra-capsular technique involves harvesting a strip of ligament from the leg and swinging it within the joins capsule to "replace" the missing cruciate ligament. We perform this technique here at Karrinyup Small Animal Hospital and have achieved good long-term outcomes for the affected leg. The disadvantage of this technique is the level of pain and discomfort immediately after the surgery.
Traditional Techniques
These procedures aim to produce dynamic stability of the knee joint, using the leg muscles to stabilise it or changing the angle of the tibial bone, without having to rely on the cruciate ligament. A few examples of current techniques are TPLO (Tibial Plateau Levelling Osteotomy) and MMP (Modified Macquet Procedure).Current Techniques
Tibial Plateau Levelling Osteotomy
TPLO - Involves creating a circular cut in the top of the tibial bone and rotating the tibial plateau. This alters the dynamic of the knee joint to "stabilise" the knee when your dog walks.
We have an experienced travelling surgeon who comes to Karrinyup Small Animal Hospital to perform this orthopaedic procedure and has had great success rates. This is the preferred surgical repair technique.
Modified Maquet Procedure
MMP - Involves creating a straight cut in the front of the tibial bone and advancing the bone forward. This creates a backward pull from the quadriceps muscle which indirectly supports the knee joint when weight is placed on the leg.
Your pet will remain in hospital for most of the day until it is fully recovered from the anesthetic and when its pain is under control.
Strict homecare following the procedure is extremely important to achieve the best outcomes. Excessive activity can result in poor healing or complications. It is important to follow the strict confinement regime to avoid surgical complications.
It is important that your dog has limited activity for six to eight weeks after surgery. Provided you are able to carry out your Veterinarian's instructions, good function should return to the limb within three months. Unfortunately, regardless of the technique used to stabilise the knee joint, arthritis is likely to develop in the joint as your dog ages. To reduce the severity of arthritis, weight control, specific joint support diets, and joint support supplements should be commenced after surgery. After Surgery
After surgery care may consist of:
Crate or cage confinement for 10-14 days until the skin incision is healed.Your pet will have intradermal sutures (dissolving sutures in the skin). This means that your pet will require post-surgery checkups but no sutures will need to be removed.Room confinement and exercise restrictions for 8-12 weeks:No access to slippery flooring or stairs.No playing with other animals, running, jumping.Walking must be on a leash and controlled.
Radiographs 8 weeks after surgery.Anti-inflammatory medications.Joint support injections eg Pentosan Polysulphate.Nutritional joint supplements eg 4-cyte or prescription joint diets.
If homecare instructions are not followed your pet may be subject to a number of complications after surgery.
Potential complications may include:Soft tissue swellingFurther meniscal injuryInfectionImplant failureWound problemPatellar luxation (kneecap luxation)Failure to return to normal functionRapidly advancing arthritisDelayed bone healing, non-healing or incorrect bone positioningBone fracture
Rehabilitation
Studies show that physical therapy can improve the recovery process following this procedure. Your Veterinarian may prescribe an exercise program specifically for your pet and advise you when to start.
Physical therapy examples:Passive range of motionSwimmingBalance exercisesLeash walking
Benefits of rehabilitation exercise:Help maintain good body conditionSpeeds recoveryPrevents further injuryImproves fitness and healthReduces the progression of osteoarthritisImproves moodDecreases painIncreases flexibilityImproves blood flow
